1.3 N.m NEMA 23 Open-Loop Stepper Motor

Available for backorder
  • Weight
    0.7 kg
  • SKU
    MOT-185

Single shaft NEMA 23, 2 phase bipolar stepper motor with 1.3 N.m of holding torque. Rated at 3.0 A phase current, weighing 0.7 kg with 55 mm body length and 6.35 mm shaft diameter.

Buy more for less:
Quantity ex GST incl GST Saving
1-4 items AUD66.53 / each AUD73.18 / each
5-9 items AUD59.88 / each AUD65.87 / each save 10%
10 or more items AUD56.55 / each AUD62.21 / each save 15%
  • AUD66.53 ex GST
  • AUD73.18 incl GST
Qty:

The 57CM13-3A is a 2 phase NEMA 23 stepper motor with 1.3 N.m (185 oz-in) holding torque. It can be implemented in many Industrial motion control applications. Built with premium quality materials including bearings and shaft made by Japanese manufacturers, this 57CM13-3A stepper motor can move the attached load at high precision and with very low motor heating & vibration.

Industrial grade small stepper motor, ideal for small CNC projects and robots. Has a holding torque of 1.3 N.m. 6.35 mm diameter round shaft. This NEMA 23 frame motor is 56.4 mm square on the face, with four M5 taped holes. The mounting holes are 47.14 mm from center to center.

Features:

  • Built with high quality materials including bearings
  • High precision, low motor heating, and low vibration

Step angle: 1.8°

Temperature rise (Max): 80 °C

Ambient temperature: -10 to 50 °C

Insulation Resistance (at 500 VDC): 100 MΩ

Shaft radial play (450 g load): ≤0.02 mm

Shaft axial play (900 g load): ≤0.08 mm

Current per phase: 3.0 A

Resistance per phase: 0.8 Ω

Inductance per phase: 2.8 mH

Holding torque: 1.3 N.m

Number of leads: 4

Rotor inertia: 0.11 kg-cm2

Weight: 0.7 kg

Body length: 55 mm
